Drum dryer machine for grape squeezing

      ENERGOTEK LLC designs and manufactures dryers for squeezing grapes (waste in the production of wine, grape juice).
The most optimal unit for drying grape pomace is a drum-type dryer. Our company has the ability to design and produce any drying drum with a capacity in the range from 0.5 tons per hour to 3 tons per hour according to customer's specifications. If higher productivity is needed, our company is ready to offer modular complexes for drying grape marc with a productivity from 6 tons per hour to 20 tons per hour.
     If it is planned to use the grape squeeze after drying as a feed or food additive, then it is necessary to remove grape seeds before drying or after drying. The removed grape seeds themselves represent a very valuable raw material for the production of grape oil. Our company also produces drying units for drying grape seed.
      A dryer drum machine for drying grape marc extracts should be aggregated with a heat generator operating either on gaseous fuel (natural gas, propane-butane mixture), or on liquid (diesel fuel, heavy fuel oil, various synthetic boiler / furnace fuels, coal water), or solid ( wood fire chambers, coal fire chambers, multi-fuel (working both on pellets, briquettes from wood raw materials, agricultural raw materials, and wood chips, wood, coal - brown, anthracite, coal grades D and G), coal-dust injection units).

      The easiest to maintain and most technologically advanced are natural gas heat generators. They can be fully automated, do not require constant monitoring. The only drawback is the cost of natural gas in Ukraine. The cost of drying is 1.5-3 times higher than when working on solid fuels or liquid (synthetic furnace fuels, products of tire pyrolysis, oils). The most significant savings can be achieved by using solid fuel heat generators. Among them, the best price / cost ratio * manufacturability has a pulverized coal heat generator. And the most economical will be a heat generator working on briquettes from sunflower husk and also on brown coal (pieces 20-100mm).
       However, they have significant disadvantages. So, for example, all solid fuel heat generators require a stoker for timely fuel supply and ash removal. When using a heat generator on wood, it is necessary to constantly monitor the moisture of the incoming firewood, since otherwise it will be impossible to achieve the necessary heat output for the drying process.A permanent warehouse for firewood with a weekly supply is also needed if you do not have a number of permanent sources of firewood and a firewood preparation area (unloading, sawing, sorting). For example, for a heat generator with a capacity of 1-1.5 MW, the required amount of firewood is 25-37 cubic meters. per day, which is equivalent to 1 truck. Thus, it turns out that depending on the wishes and needs of the customer, the type of heat generator used is not always obvious. Sometimes it is more advisable to put a heat generator running on diesel fuel, or on natural gas and not have unnecessary trouble.
      Also, along with the heat generator, for the operation of the drying drum, a smoke exhaust is necessary, which ensures the suction of the necessary air for combustion, its passage through the drying drum, cyclone and the evacuation of moisture evaporated from the ores. For each capacity in tons per hour, taking into account the humidity at the inlet and outlet of the dryer drum, the properties of the grape squeeze, porosity, etc., a smoke exhauster with the necessary parameters is specially calculated, designed and produced.
      The third necessary element for the proper conduct of the drying process of grape squeeze is the presence of dust precipitating cyclone. Grape squeezing is a low-dusting material, but nevertheless requires a system for trapping small particles. The parameters of the cyclone depend on the performance of the dryer drum, the amount of moisture removed from the material, such as a heat generator. Therefore, in each case, depending on the configuration, we select cyclones individually.
       When purchasing equipment in our company, we provide all the necessary documents - data sheet, operation manual, installation and aggregation schemes with the supply and unloading of material. We also provide any feasible advisory assistance in the preparation of project documentation for coordination with government agencies.
      Warranty - 24 months. At the end of the warranty - after-sales service.


     The price is only for a tumble dryer of the minimum configuration and minimum performance. The price does not include heat generator, cyclone, smoke exhaust.
